| Item | Requirements | Item | Requirements |
| Tensile Strength | ≥13.1MPa | Water Absorption | 1-2g/100cm2 |
| Break Elongation | ≥11.1% | Breaking Strength | 0.08-0.1MPa |
| Impact Strength | ≥32.4KJ/m2 | Breaking Elongation | 4-6% |
| Bending Strength | ≥15.7MPa | Compressive Strength | 0.1-0.24MPa |
| Weather Resistance After total aging energy≥3.5GJ/m2 | Break Elongation %≥ | 10 |
| Oxidative Induction Time 200°Cmm≥ | 10 |
| Characteristic |
| * Good flexibility, excellent impact resistance, particularly suitable for construction in open sea | * Lightweight weight easy to install and handle, low costs for moving | * High corrosive resistance, 3 times longer life than steel floats | * Higher cost performance than steel float |
Key Features:
Sturdy HDPE Outer Shell:
Highly resistant to corrosion, UV rays, and physical damage, ensuring long-lasting protection in marine conditions.
Efficient Buoyancy with EPS Foam Core:
Ensures strong flotation, preventing pipeline sinking or misalignment even in turbulent waters.
Designed for Harsh Environments:
Built to endure impacts, weather extremes, and constant exposure to saltwater, providing reliable performance year-round.
Custom-Fit Sizes Available:
Tailored to suit various pipeline diameters, offering flexibility for different project requirements.
Easy Installation and Handling:
Lightweight design simplifies installation, reducing operational downtime and labor costs.
Benefits:
Improved Pipeline Efficiency:
Keeps pipelines properly aligned and afloat, minimizing drag and maximizing material flow.
Long-Lasting Durability:
High-quality materials ensure the hose floats perform effectively over extended periods, reducing the need for replacements.
Cost-Effective Solution:
By reducing pipeline wear and the need for frequent maintenance, these floats contribute to lower overall operational costs.
Environmentally Friendly:
The non-toxic, recyclable materials used in the construction are in line with sustainable and eco-friendly practices.
Applications:
※ Dredging operations and pipeline transportation of sediments.
※ Offshore oil and gas projects requiring floating pipelines.
※ Marine construction and environmental restoration work.
| I.D. | O.D. | Length | Thickness | Net Buoyancy |
| mm | mm | mm | mm | KGS/Float |
| 160-180 | 500 | 800 | 4 | 280 |
| 225 | 600 | 700 | 4 | 320 |
| 280 | 700 | 900 | 4 | 450 |
| 340 | 1000 | 1000 | 6 | 500 |
| 410 | 1100 | 1100 | 6 | 550 |
| 460 | 1200 | 1200 | 6 | 1200 |
| 510 | 1300 | 1300 | 7 | 1250 |
| 560 | 1300 | 1500 | 8 | 1360 |
| 610 | 1400 | 1600 | 8 | 1600 |
| 630 | 1480 | 1600 | 8 | 1950 |
| 680 | 1550 | 1800 | 8 | 2200 |
| 730 | 1620 | 1900 | 9 | 2300 |
| 780 | 1700 | 2000 | 9 | 2700 |
| 840 | 1850 | 2100 | 12 | 3200 |
| 890 | 2000 | 2400 | 12 | 4600 |
| 940 | 2040 | 2500 | 13 | 4900 |
| 1150 | 2400 | 2600 | 14 | 6500 |
| *NOTE: The floaters customized are available. |
FAQ
Q1: What materials are used in the construction of your hose floats?
A1: Our hose floats are made with a high-density polyethylene (HDPE) outer shell for durability and an expanded polystyrene (EPS) foam core for excellent buoyancy.
Q2: Are these hose floats customizable?
A2: Yes, our hose floats can be customized to fit different pipeline diameters and specific project requirements, ensuring optimal performance for each operation.
Q3: Can your hose floats withstand harsh marine conditions?
A3: Absolutely. The HDPE outer shell is highly resistant to corrosion, UV radiation, and saltwater, ensuring that the hose floats remain durable and reliable even in challenging marine environments.
Q4: What are the typical applications for your hose floats?
A4: Our hose floats are commonly used in dredging operations, offshore floating pipelines, marine construction, and environmental restoration projects, where stability and buoyancy are critical.
